SF-055 Oculink SFF-8612 8611 to U.2 Kit M-Key to NVME PCIe SSD and NGFF to SATA Adapter for Mainboard

• Oculink 4x connectors are internal and external small form factor PCI-E connectors and cables optimized for the client and market
• Supports M.2 modules in format 2280, 2260, 2242 and 2230 with key B or key B+M based on SATA
• The card not work for NVME M-key SSD to SATA host, Also can't work for NGFF B-key SD to oculink host
• It only can work for NVME M-key SSD to oculink or NGFF B-key SD to SATA
• Hyper Kit Storage controller,Ultra PCI-E Card (PCIe 3.0 x4),The card work for PCI-E SSD.(Not work for SAS or Slimeline SAS HD)

This U.2 M.2 converter enables two different usage applications:

• 1. One M.2 PCIe SSD in 2280, 2260, 2242 and 2230 format can be connected and used as a replacement for a 2.5inch HDD. The converter can be installed into the system internally through the SFF-8611/8612 oculink interface.
• 2. One M.2 SATA SSD in 2280, 2260, 2242 and 2230 format can be connected and used as a replacement for a 2.5inch HDD. The converter can be installed into the system internally through the SATA 22pin interface.
• 3. It can't convert NVME to SATA, also can't covert NGFF/SATA to Oculink.
